AQUADRAIN® Drainage Composite

Our Unmatched Solution for Foundation Drainage

With millions of square feet installed, AQUADRAIN® sets the bar for foundation drainage, with over 30 years of unsurpassed performance, ease of installation and versatility.



It’s simply the best.

Aquadrain-1697-cmyk



Exceptional waterproofing technology

For foundation installations, AQUADRAIN® protects from water penetration while providing more predictable drainage than aggregate. Its three-dimensional core structure makes it functional for both horizontal and vertical water flow, while its geotextile filter fabric holds soil particles yet still allows high-volume passage of water through the drainage core.



Easy installation saves you money

Lightweight and easy to install, AQUADRAIN® is also easy on your budget—installation is quick and requires no heavy equipment or skilled labor, saving you time and saving your money.



How it does it

The AQUADRAIN® system employs a non-woven polypropylene filter fabric covering either a high strength HDPE geonet core for high compressive strength properties with low to moderate flow, or covering a three-dimensional polypropylene formed dimple core that provides compressive strength and collects water for flow to drainage discharge pipes.



Versatile to meet specific needs on any site

AQUADRAIN® is available in series of varying flow rates and compressive strengths to meet the requirements of any site:

  • AQUADRAIN® 10X
    A two-part prefabricated sheet drain consisting of a three-dimensional polypropylene formed dimple core covered with a non-woven polypropylene filter fabric bonded to one side. The formed dimple core provides compressive strength and collects water for flow to drainage discharge pipes. Its polypropylene core resists chemical attack and degradation in soil.
  • AQUADRAIN® 15X
    A two-part prefabricated sheet drain composite consisting of a three-dimensional polypropylene formed dimple core covered with a non-woven polypropylene filter fabric on one side. The formed dimple core provides compressive strength and collects water for flow to drainage discharge pipes. Its polypropylene core resists chemical attack and degradation in soil.
  • AQUADRAIN® 15XP
    A three-part prefabricated sheet drain composite consisting of a three-dimensional polypropylene formed dimple core covered with a non-woven polypropylene filter fabric bonded to one-side and a polymeric film bonded to the other. The formed-dimple core provides compressive strength and collects water for flow to drainage discharge pipes.
  • AQUADRAIN® 18H
    A two-part prefabricated sheet drain consisting of a three-dimensional polypropylene formed dimple core covered with a heavy 8-oz. nonwoven polypropylene filter fabric on one side. The formed dimple core provides compressive strength and collects water for flow to drainage discharge pipes. The polypropylene core resists chemical attack and degradation in soil.
  • AQUADRAIN® 20H
    A two-part prefabricated sheet drain consisting of a three-dimensional polypropylene formed dimple core covered with a woven polypropylene filter fabric bonded to one-side. The formed dimple core provides compressive strength and collects water for flow to drainage discharge pipes. The filter fabric allows water or other liquids to pass into the drainage core while restricting the passage of soil particles. The filter fabric is bonded to each dimple to minimize fabric intrusion into the core resulting from backfill pressure. The polypropylene core resists chemical attack and degradation in soil.
  • AQUADRAIN® 30H
    A two-part prefabricated sheet drain composite consisting of a three-dimensional polypropylene formed dimple core covered with a woven polypropylene filter fabric bonded to one side. The formed-dimple core provides compressive strength and collects water for flow to drainage discharge pipes. Its polypropylene core resists chemical attack and degradation in soil.
  • AQUADRAIN® G10
    A two-part prefabricated drainage composite consists of a high strength HDPE geonet core with a non-woven polypropylene filter fabric bonded to one side. AQUADRAIN G10 is designed for horizontal and vertical applications requiring a high compressive strength core with exceptional fabric strength properties. Its polypropylene core resists chemical attack and degradation in soil.
  • AQUADRAIN® G20
    A two-part prefabricated drainage composite consists of a high strength HDPE geonet core with a non-woven polypropylene filter fabric bonded to both sides. AQUADRAIN G20 is designed for horizontal and vertical applications requiring very high compressive strength with low to moderate flow properties. Its polypropylene core resists chemical attack and degradation in soil.
  • AQUADRAIN® GS25
    A three-part prefabricated drainage and protection composite consisting of a high strength HDPE geonet core with nonwoven polypropylene filter fabrics bonded to both sides. AQUADRAIN G25 is designed for horizontal and vertical applications requiring very high compressive strength properties with low to moderate flow properties. Its polypropylene core resists chemical attack and degradation in soil.
  • AQUADRAIN® 100BD
    A two-part prefabricated drainage composite consisting of a 300 mm (12”) high by 25 mm (1”) thick, 3-dimensional polystyrene core which is wrapped with a heavy 6-oz. non-woven polypropylene filter fabric.
Two-Part SheetThree-Part Sheet3-Dimensional Polypropylene Formed Dimple CoreHigh Strength HDPE Geonet CorePolymeric Film on One Side
AQUADRAIN 10XX X
AQUADRAIN 15XX X
AQUADRAIN 15XP XX X
AQUADRAIN 18HX X
AQUADRAIN 20HX X
AQUADRAIN 30HX X
AQUADRAIN G10X  X
AQUADRAIN G20X  X
AQUADRAIN GS25 X X
AQUADRAIN 100BDX

CETCO—Pioneer and leader in waterproofing

CETCO is the leader and pioneer in cutting-edge waterproofing membranes. Around the globe, our innovative teams of clay mineralogists, chemists, and polymer scientists transform ordinary minerals into extraordinary technology to solve day-to-day problems worldwide.
